Carbon Steel ASTM A513 Grade DOM Tubing Suppliers Manufacturer & Exporter in India
Amardeep Steel Center is one of the renowned DOM tube suppliers, stockists, manufacturers & exporters of carbon steel ASME A513 DOM seamless tubes that are being created and planned as per worldwide quality norms. A513 DOM tubes are valued due to the different great credits that they hold.. High solidness, high adaptability, life span, mechanical strength, resistance to corrosives, pitting/oxidation opposition, stress consumption, breaking obstruction, general erosion, and cleft erosion have settled on it as an optimal choice for different applications.
Amardeep Steel Center is known as the solid exporter, provider, Dom tube supplier, and stockist of generally excellent low-temperatureOM tubes. Carbon Steel ASME SA513 DOM Seamless Tubes are accessible in acceptable quality and in various principles, details, and measurements according to the purchaser's necessities and prerequisites. In the interim, the cylinders are made accessible in different specialized determinations that affirm public and worldwide item quality guidelines.
The ASTM A513 equivalent is DIN 17175 Grade 16Mo5, ASTM A513, and ASME SA513.. ASTM A513 detail covers electric-resistance welded carbon steel tubing for use as mechanical and decorative tubing. A definitive elasticity of SA 513 material is determined by isolating the space of the steel by the pressure set on it, which is communicated ds or tons per square inch of material. Elasticity is additionally a significant proportion of its capacity to act in an application.
Types of ASTM A513 DOM Tubes
SA 513 is a business and private item that needs an extreme and strong metal tubing structure that upholds the roughness of its applications. ASTM A513 T5 is profoundly strong,, which offers hearty primary help for the hardcoretal items that are utilized each day. ASTM A513 Type 1 is made from low-carbon steel. Which is normally accessible in hot-moved, dark,k, and hot-rolled. It is delivered to nearer dimensional tolerances than A500 and sciences that take into account twisting. It is utilized for furniture, machine parts, stockpiling racks, walls, and so forth.
ASTM A513 tubing gives various favorable characteristics to a wide scope of enterprises all through the world. The absolute most unmistakable useful characteristics of SA 513 tubing are its solidness, its ability to work to tight resistances, and its less exorbitant cost. ASTM A513 chemical composition is iron with added carbon, phosphorus, manganese, silicon, and silver. SA 513 steel tubing is utilized in an assortment of agrarian, modern, and transportation-related end occupations.
ASTM A513 Type 5 DOM tubing is produced by utilizing excellent carbon steel C1020 strip, and it is framed and electric obstruction welded into its essential shape. Subsequent to strengthening to deliver a uniform grain structure in general, over a mandrel, it is then virus attracted to give it these benefits: uniform concentricity around the focal hub, denser surface, closer resistances, uniform divider thickness, and higher actual properties. As one of the trusted Dom Tube Suppliers in India, Amardeep Steel ensures strict quality control and global standards compliance for every product delivered.
ASTM A513 DOM Tube Grades
ASTM A513 Tubing Specification
| Sizes |
0.188” to 12.000” O.D. with 0.028” to 0.625” Wall
Thickness |
| In Length of |
Stocked in 17.000’ - 24.000’ random lengths (cut to
length available) Single Random, Double Random & Required Length, Custom Size - 12 Meter
lengths
|
| Value Added Service |
Draw & Expansion as per required Size & Length
Heat Treatment,
Bending,
Annealed,
Machining Etc.
|
| End Connections |
Plain, Screwed, Bevel, Threaded
|
| Type |
Seamless / Welded / ERW / Fabricated / CDW
|
| ASTM A513/ ASME SA513 Alloy Steel Tuhe
End
| Plain End, Beveled End, Threaded
|
| Outside Coating & Finish |
Black Painting, Anti-Corrosion Oil, Galvanised
Finish, Finish as per customer Requirements
|
Carbon Steel ASTM A513 Equivalent Indian Standard
| DIN |
EN |
BS |
NFA |
ASTM |
ASME |
| DIN 17175 Grade 16Mo5 |
- |
- |
ASTM A513 |
ASTM A513 |
SA 513 |
ASTM A513 Chemical Composition
| Grade Designation |
Chemical Composition Limits, % |
|
Carbon |
Manganese |
Phosphorus, max |
Sulfur, max |
| 1010 |
0.05-0.15 |
0.30-0.60 |
0.035 |
0.035 |
| 1015 |
0.10-0.20 |
0.30-0.60 |
0.035 |
0.035 |
| 1020 |
0.15-0.25 |
0.30-0.60 |
0.035 |
0.035 |
| 1026 |
0.22-0.28 |
0.30-0.90 |
0.035 |
0.035 |
A513 Round and Square Steel Tube Hardness Limits and Tensile Properties
| Yield Stress, Ksi (MPa), min |
Ultimate Stress, ksi (MPa), min |
Elongation in 2 in. or 50 mm. % min
|
RB min |
RB max |
|
| 1008 |
30 (207) |
42 (290)
|
15 |
50 |
|
| 1010 |
32 (221) |
45 (310)
|
15 |
55 |
|
| 1015 |
35 (241) |
48 (331)
|
15 |
58 |
|
| 1020 |
38 (262) |
52 (359)
|
12 |
62 |
|
| 1026 |
45 (310) |
62 (427)
|
12 |
68 |
|
| 1008 |
23 (159) |
38 (262)
|
30 |
|
65 |
| 1010 |
25 (172) |
40 (276)
|
30 |
|
65 |
| 1015 |
30 (207) |
45 (310)
|
30 |
|
70 |
| 1020 |
35 (241) |
50 (345)
|
25 |
|
75 |
| 1026 |
40 (276) |
60 (414)
|
25 |
|
85 |
| 1008 |
38 (262) |
38 (262)
|
8 |
65 |
|
| 1010 |
40 (276) |
40 (276)
|
8 |
65 |
|
| 1015 |
45 (310) |
45 (310)
|
8 |
67 |
|
| 1020 |
50 (345) |
50 (345)
|
8 |
70 |
|
| 1026 |
55 (379) |
55 (379)
|
7 |
77 |
|
| 1008 |
50 (345) |
60 (414)
|
5 |
73 |
|
| 1010 |
50 (345) |
60 (414)
|
5 |
73 |
|
| 1015 |
55 (379) |
65 (448)
|
5 |
77 |
|
| 1020 |
60 (414) |
70 (483)
|
5 |
80 |
|
| 1026 |
70 (483) |
80 (552)
|
5 |
85 |
|
| Mandrel-Drawn Stress-Relieved Tubing |
| 1008 |
45 (310) |
45 (310)
|
55 (379) |
12 |
68 |
| 1010 |
45 (310) |
45 (310)
|
55 (379) |
12 |
68 |
| 1015 |
50 (345) |
50 (345)
|
60 (414) |
12 |
72 |
| 1020 |
55 (379) |
55 (379)
|
65 (448) |
10 |
75 |
| 1026 |
65 (448) |
65 (448)
|
75 (517) |
10 |
80 |
Applications of Carbon Steel ASTM A513 DOM Tubes
- Hydraulic & Mechanical Cylinders : ASTM A513 DOM tubes provide smooth, uniform walls and high structural strength, making them ideal for hydraulic cylinders, pistons, and other precision mechanical parts.
- Automotive & Machinery Components : Their durability and precise dimensions make these tubes perfect for building automotive frames, machine parts, and assembly fixtures that demand consistent performance.
- Furniture & Storage Racks : With excellent formability and finish, these tubes are commonly used in metal furniture frames and industrial storage racks, offering both strength and a clean aesthetic.
- Construction & Structural Applications : Thanks to their ability to withstand stress and resist corrosion, ASTM A513 DOM tubes are well-suited for scaffolding, support structures, and various architectural elements.
- Agricultural & Transportation Uses : The tubes' robustness and wear resistance allow them to perform reliably in agricultural machinery, vehicle chassis, and transport equipment that face tough, real-world conditions.
Advantages and Benefits of ASTM A513 Type 5 Tubes
- Durable material
- Suitable to tight tolerances
- Consumer product applicable
- Economical price
1. Who are the leading DOM tube suppliers in India?
Amardeep Steel Center is one of the leading DOM tube suppliers in India, offering ASTM A513 carbon steel DOM tubes with international quality standards, precise dimensions, and excellent durability.
2. What is ASTM A513 DOM tubing?
ASTM A513 DOM Tubing (Drawn Over Mandrel) is a high-quality carbon steel tube that provides superior dimensional accuracy, strength, and uniform wall thickness. It is widely used in automotive, construction, machinery, and structural applications.
3. What are the key features of Carbon Steel ASTM A513 DOM Tubes?
These tubes are known for their high strength, corrosion resistance, durability, close tolerances, and excellent mechanical properties, making them suitable for heavy-duty and precision applications.
4. What are the applications of ASTM A513 DOM tubes?
ASTM A513 DOM Tubes are commonly used in automotive parts, industrial machinery, furniture, storage systems, construction equipment, hydraulic applications, and general engineering purposes.
5. How do ASTM A513 DOM tubes compare with other carbon steel tubing?
Compared to other carbon steel tubes, ASTM A513 DOM tubes are manufactured using the drawn-over-mandrel process, which ensures tighter tolerances, smoother finishes, greater strength, and uniformity in structure.
