Aluminium Pipe & Tube Supplier, Manufacturer & Exporter in India
Amardeep Steel is the most reliable and trusted supplier of high-quality aluminium pipes and tubes to customers all over the world. Our products are manufactured using high-quality materials that meet all the international standards, and hence durable, corrosion and reliable against various uses. We offer aluminium square tubing, aluminium rectangular tubing, aluminium round, and aluminium box sections in a variety of sizes, shapes, and thicknesses that meet various industry requirements, including construction, automobile, oil and gas, among others.
Our aluminium pipes are constructed to handle high-pressure conditions, and they come in various types, e.g., seamless, welded, and ERW. We also supply aluminium compressed air piping to industries that require effective air piping. These aluminium pipes and tubes are light, powerful, and intended to serve well in very important applications.
The use of aluminum pipes and tubes is largely attributed to their good characteristics, such as being of high strength, durable, heat and corrosion-resistant. They are applied in such industries as railways, petrochemicals, pharmaceuticals and marine systems. Structural frameworks are normally done by the use of aluminium round tubes, though aluminium square tubing and aluminium rectangular tubing can be applied in certain projects where certain shapes and sizes are needed.
Though the aluminium pipes and aluminium tubes may appear similar, there are differences between the two. Pipes are circular and their size is determined by the inner diameter, whereas tubes are circular, square, or rectangular and their size is determined by their external size and thickness. This flexibility enables them to satisfy a certain industrial requirement.
In Amardeep Steel, we have maintained high-quality standards by carrying out a number of tests, such as hardness tests, hydrostatic tests, and corrosion resistance tests. Packaging is also customized to deliver safely. In case you are in need of quality suppliers of aluminium tubes or aluminium pipes close to me, Amardeep Steel would be available to sell you the best products.
High-Performance Aluminum Pipes & Tubes for Industrial Applications
Aluminium 6061 Seamless Pipes are an excellent choice when it comes to avoiding spalling in addition to offering high resistance to chloride stress corrosion cracking. Additionally, aluminium 6082 welded pipes are common in industries such as food processing, pharmaceuticals, gasoline, and plastics since they are highly strong and resistant to corrosion. The presence of aluminium 5086 ERW pipes is associated with the formation of a protective oxide layer that increases the life of pipes in case they are subjected to increased temperatures. These pipes are suitable to use in the harsh environment, as they are stable and they have a long life in the different industrial areas.
We have aluminium square tubing ranging to aluminium 6063 square pipes which are not only tough and strong but also maintain such properties at cryogenic temperatures. Aluminium 7075 rectangular pipes have low thermal expansion and can be used in the aerospace and automotive industries where high thermal expansion is not acceptable. Both aluminium 5083 square tubes and aluminium 6061 square tubes are ideal in production of valve, pumps and process control gadgets particularly in the oil and gas industry.
Amardeep Steel is the supplier of aluminium tube or aluminium pipe around me and delays its products promptly and of high quality to satisfy your needs. Today, contact us to know more about our wide collection of aluminium pipes and aluminium tubes and how they may be used in supporting your industrial needs. Give us a call and get in touch!
Aluminium Tube & Pipe Specification
| Grades | 5083, 6061, 6082, 7075, 7001, 7045, 7050, 3003, 2014, 2024, 2017, 2011, 1200 |
|---|---|
| Size | 15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD) |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | As per customer’s requirement (Maximum upto 7 meters) |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Surface | Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE |
| Test | Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Flaring Test, Bending Test, Hardness Test, Blow Test, Impact Test etc), Exterior Size Inspection |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Mill Test Certificate | EN 10204/3.1B |
Aluminium Tube & Pipe Chemical Composition
| Grade | Si | Fe | Cu | Zn | Mn | Mg | Ti | Cr | Al | Others(Total) |
|---|---|---|---|---|---|---|---|---|---|---|
| Aluminium | 0.40 – 0.80 | 0.70 max | 0.15-0.40 | 0.25 max | 0.15 | 0.8-1.2 | 0.15 max | 0.04-0.35 | Balance | 0.15 max |
Aluminium Pipe & Tube Mechanical Properties
| Temper | Tensile | Hardness | ||||
|---|---|---|---|---|---|---|
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 45 | 310 | 21 | 145 | 25 | 65 |
Standard Specification for Aluminium Pipes & Tubes
| ASTM B241 / ASME SB241 | Standard Specification for Aluminum and Aluminum | Alloy Seamless Pipe and Seamless Extruded Pipes |
|---|---|---|
| ASTM B345 / ASME S345 | Standard Specification for Aluminum and Aluminum | Alloy Seamless Pipe and Seamless Extruded Pipe for Gas and Oil Transmission and Distribution Piping Systems. |
| ASTM B429 / ASME SB429 | Standard Specification for Aluminum | Alloy Extruded Structural Pipe and Tube |
| EN AW-AlMg1SiCu | Standard Specification for Aluminum and Aluminum | Alloy Round Pipe |
| ISO AlMg1SiCu | Standard Specification for Aluminum and Aluminum | Alloy Cold / Hot Rolled Piping |
Physical Property for Aluminium Pipe & Tube
| Physical Property | Value |
|---|---|
| Density | 2,70 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.4 x 10^-6 /K |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 170 W/m.K |
| Electrical Resistivity | %43 IACS |
Aluminium Pipe & Tube Size Chart | Weight Chart
| OM SIZE | OUTSIDE DIA (D) |
WALL THICKNESS IN MM (T)
|
METRIC SIZE | ||||||
|---|---|---|---|---|---|---|---|---|---|
| SCH 10S | SCH 10 | SCH 40 S |
STD Weight | SCH 40 | SCH 80s | SCH 80 | |||
| 1/4 “ | 13.72 | 1.65 | 2.24 | 2.24 | 2.24 | 3.02 | 3.02 | ||
| 3/8″ | 17.15 | 1.65 | 2.31 | 2.31 | 2.31 | 3.2 | 3.2 | ||
| 1/2″ | 21.34 | 2.11 | 2.77 | 2.77 | 2.77 | 3.73 | 3.73 | 15 | |
| 3/4″ | 26.67 | 2.11 | 2.87 | 2.87 | 2.87 | 3.91 | 3.91 | 20 | |
| 1″ | 33.4 | 2.77 | 3.38 | 3.38 | 3.38 | 4.55 | 4.55 | 25 | |
| 1 1/4″ | 42.16 | 2.77 | 3.56 | 3.56 | 3.56 | 4.85 | 4.85 | 32 | |
| 1 1/2″ | 48.26 | 2.77 | 3.68 | 3.68 | 3.68 | 5.08 | 5.08 | 40 | |
| 2″ | 60.32 | 2.77 | 3.91 | 3.91 | 3.91 | 5.54 | 5.54 | 50 | |
| 2 1/2″ | 73.02 | 3.05 | 5.16 | 5.16 | 5.16 | 7.01 | 7.01 | 65 | |
| 3″ | 88.9 | 3.05 | 5.49 | 5.49 | 5.49 | 7.62 | 7.62 | 80 | |
| 3 1/2″ | 101.6 | 3.05 | 5.74 | 5.74 | 5.74 | 8.08 | 8.08 | 90 | |
| 4″ | 114.3 | 3.05 | 6.02 | 6.02 | 6.02 | 8.56 | 8.56 | 100 | |
| 5″ | 141.3 | 3.4 | 6.55 | 6.55 | 6.55 | 9.52 | 9.52 | 125 | |
| 6″ | 168.27 | 3.4 | 7.11 | 7.11 | 7.11 | 10.97 | 10.97 | 150 | |
| 8″ | 219.07 | 3.76 | 8.18 | 8.18 | 8.18 | 12.7 | 12.7 | 200 | |
| 10″ | 273.05 | 4.19 | 9.27 | 9.27 | 9.27 | 12.7 | 15.08 | 250 | |
| 12″ | 323.85 | 4.57 | 9.52 | 9.52 | 10.31 | 12.7 | 17.47 | 300 | |
| 14″ | 355.6 | 4.77 | 6.35 | 9.52 | 11.12 | 19.05 | 350 | ||
| 16″ | 404.6 | 4.77 | 6.35 | 9.52 | 12.7 | 21.44 | 400 | ||
| 18″ | 457.2 | 4.77 | 6.35 | 9.52 | 14.27 | 23.82 | 450 | ||
Aluminium Pipe HSN Code
| Material | HS Code |
|---|---|
| Al Pipes | 7608 |
Schedule Chart of the Aluminium Pipe
| Outside Diameter (OD) | SCH 80 | SCH 80S | SCH 40 | SCH 40S | SCH 10 | SCH 10S |
|---|---|---|---|---|---|---|
| 13.72 | 3.02 | 3.02 | 2.24 | 2.24 | — | 1.65 |
| 17.15 | 3.20 | 3.20 | 2.31 | 2.31 | — | 1.65 |
| 21.34 | 3.73 | 3.73 | 2.77 | 2.77 | — | 2.11 |
| 26.67 | 3.91 | 3.91 | 2.87 | 2.87 | — | 2.11 |
| 33.40 | 4.55 | 4.55 | 3.38 | 3.38 | — | 2.77 |
| 42.16 | 4.85 | 4.85 | 3.56 | 3.56 | — | 2.77 |
| 48.26 | 5.08 | 5.08 | 3.68 | 3.68 | — | 2.77 |
| 60.32 | 5.54 | 5.54 | 3.91 | 3.91 | — | 2.77 |
| 73.02 | 7.01 | 7.01 | 5.16 | 5.16 | — | 3.05 |
| 88.90 | 7.62 | 7.62 | 5.49 | 5.49 | — | 3.05 |
| 101.60 | 8.08 | 8.08 | 5.74 | 5.74 | — | 3.05 |
| 114.30 | 8.56 | 8.56 | 6.02 | 6.02 | — | 3.05 |
| 141.30 | 9.52 | 9.52 | 6.55 | 6.55 | — | 3.40 |
| 168.27 | 10.97 | 10.97 | 7.11 | 7.11 | — | 3.41 |
| 219.07 | 12.70 | 12.70 | 8.18 | 8.18 | — | 3.76 |
| 273.05 | 15.08 | 12.70 | 9.27 | 9.27 | — | 4.19 |
| 323.85 | 17.47 | 12.70 | 10.31 | 9.52 | — | 4.57 |
| 355.60 | 19.05 | — | 11.12 | — | 6.35 | 4.77 |
| 404.60 | 21.44 | — | 12.70 | — | 6.35 | 4.77 |
| 457.20 | 23.82 | — | 14.27 | — | 6.35 | 4.77 |
Dimension Chart of Aluminium Pipe
| Metric Diameter (mm) | Imperial Diameter (Inches) |
|---|---|
| 6.3 | 1/4 |
| 9.5 | 3/8 |
| 12.7 | 1/2 |
| 15.8 | 5/8 |
| 19.0 | 3/4 |
| 22.2 | 7/8 |
| 25.4 | 1 |
| 31.8 | 1 1/4 |
| 38.1 | 1 1/2 |
| 41.3 | 1 5/8 |
| 44.5 | 1 7/8 |
| 48.4 | 1 15/16 |
| 50.8 | 2 |
| 57.2 | 2 1/4 |
| 63.5 | 2 1/2 |
| 69.9 | 2 3/4 |
| 76.2 | 3 |
| 101.6 | 4 |
| 127.0 | 5 |
| 139.7 | 5 1/2 |
| 152.4 | 6 |
Key Applications of Aluminium Pipes & Tubes Across Industries
Aluminum pipes and tubes have a wide range of applications across various industries. Some of the common applications of aluminium pipes and tubes are:
- Construction:Aluminium pipes and tubes are widely used in construction due to their lightweight, durability, and corrosion resistance properties. They are used in building structures, roofing, curtain walls, and other architectural applications.
- Automotive: Aluminium pipes and tubes are used in the automotive industry due to their lightweight and high strength properties. They are used in exhaust systems, engine cooling systems, and air conditioning systems.
- Aerospace:Aluminium pipes and tubes are used in the aerospace industry due to their lightweight and high strength properties. They are used in the construction of aircraft fuselages, wings, and other structural components.
- Electrical:Aluminium pipes and tubes are used in the electrical industry due to their good electrical conductivity and corrosion resistance properties. They are used in power transmission lines, bus bars, and other electrical applications.
- Marine:Aluminium pipes and tubes are used in the marine industry due to their corrosion resistance properties. They are used in the construction of boat and ship structures, as well as in marine equipment and fittings.
- Packaging:Aluminium pipes and tubes are used in the packaging industry due to their lightweight and corrosion resistance properties. They are used in the production of tubes for cosmetics, pharmaceuticals, and other products.
- Industrial:Aluminium pipes and tubes are used in various industrial applications such as heat exchangers, air conditioning systems, and fluid handling systems due to their lightweight, high strength, and corrosion resistance properties.
FAQs
1. What is an aluminum tube used for?
Aluminum tubes and pipes have a high thermal conductivity, which makes them ideal for refrigerators, HVAC, and engine parts.
2. Is the aluminum tube easy to bend?
Aluminum alloy 6063 is a good choice, for example, while 6082 is more difficult. I would avoid using alloys in the 2xxx family because they are so strong and therefore difficult to form. However, in the right temper, the bending of those alloys is also possible.
3. Is aluminum tubing as strong as steel?
The tensile strength of standard structural steel can range from 400 MPA to 500 MPA (58,000 to 72,500 psi), while aluminum's is typically around 90 MPA (13,000 psi). This means steel can withstand significantly greater tension before failure than aluminum.
4. Is aluminum more expensive than steel?
However, it's essential to delve deeper and differentiate between specific types of steel. Mild and carbon steels typically come at a lower cost than aluminum, whereas stainless steel carries a higher price tag than aluminum.
5. What is the difference between an aluminium pipe and an aluminium tube?
The main difference lies in how they are measured. Aluminium pipes are typically round and measured by their internal diameter, making them suitable for transporting fluids and gases. Aluminium tubes can be round, square, or rectangular and are measured by their outer dimensions and wall thickness, making them ideal for structural and engineering applications.
6. What are the common applications of aluminium pipes and tubes?
Aluminium pipes and tubes are widely used in industries like construction, automotive, aerospace, marine, oil & gas, chemical processing, and power generation. They are also used in air systems, architectural frameworks, and equipment manufacturing because of their strength, lightweight, and corrosion resistance.
7. Which aluminium grades are commonly used for pipes and tubes?
Popular grades include Aluminium 6061, 6082, 5083, 7075, and 6063. Each grade has unique properties — for example, 6061 offers excellent corrosion resistance, 6082 provides high strength, 5083 is great for marine applications, and 7075 is preferred in aerospace and automotive due to its toughness.
8. What are the advantages of using aluminium pipes and tubes?
Aluminium pipes and tubes are lightweight yet strong, resistant to corrosion, durable in high-temperature environments, and easy to fabricate. They also have excellent thermal and electrical conductivity, making them suitable for a wide range of critical industrial applications.
9. Do you provide customised aluminium pipe and tube sizes?
Yes, Amardeep Steel offers custom aluminium pipes and tubes in various shapes (round, square, and rectangular), sizes, wall thicknesses, and finishes to match specific project requirements. We also provide testing and safe packaging for reliable delivery worldwide.
